Description
Our Blade Cutterhead features carbide-tipped Blade Cutters, most effective in soft to medium/soft formations such as dirt, clay, mild sandstone, and light shale.
| Description | Part # | Lbs. | Kg. |
| 3 1/4″ (83mm) DK Blade Cutterhead – 7 1/2″ (190mm) O.D. | ACH314250 | 11 | 5 |
| 3 3/4″ (95mm) DK Blade Cutterhead – 8 1/2″ (216mm) O.D. | ACH334250 | 16 | 7.3 |
| 3 3/4″ (95mm) DK HD Blade Cutterhead – 8 1/2″ (216mm) O.D. | ACH334250HD | 16 | 7.3 |
| 4 1/4″ (108mm) DK Blade Cutterhead – 8 3/4″ (222mm) O.D. | ACH414250 | 16 | 7.3 |
| 4 1/4″ (108mm) DK HD Blade Cutterhead – 8 3/4″ (222mm) O.D. | ACH414250HD | 16 | 7.3 |
| 6 1/4″ (159mm) DK Blade Cutterhead – 11″ (279mm) O.D. | ACH614250 | 23 | 10.4 |
| 6 1/4″ (159mm) DK HD Blade Cutterhead – 11″ (279mm) O.D. | ACH614250HD | 23 | 10.4 |
| 7 1/4″ (184mm) DK HD Blade Cutterhead – 12″ (310mm) O.D. | ACH714250HD | 33 | 15 |
| 8 1/4″ (210mm) DK HD Blade Cutterhead – 13″ (330mm) O.D. | ACH814250HD | 35 | 15.9 |
| 3 1/4″ (83mm) TK Blade Cutterhead – 7 1/2″ (190mm) O.D. | ACH314350 | 11 | 5 |
| 4 1/4″ (108mm) TK Blade Cutterhead – 8 3/4″ (222mm) O.D. | ACH414350 | 12 | 5.4 |
| 4 1/4″ (108mm) TK HD Blade Cutterhead – 8 3/4″ (222mm) O.D. | ACH414350HD | 16 | 7.3 |
| 6 5/8″ (169mm) TK Blade Cutterhead – 11 1/2″ (292mm) O.D. | ACH658350 | 28 | 12.7 |
| 6 5/8″ (169mm) TK HD Blade Cutterhead – 11 1/2″ (292mm) O.D. | ACH658350HD | 29 | 13.2 |
| 8 1/4″ (210mm) TK HD Blade Cutterhead – 13″ (330mm) O.D. | ACH814350HD | 35 | 15.9 |
| 10 1/4″ (260mm) TK HD Blade Cutterhead – 15″ (381mm) O.D. | ACH1014350HD | 52 | 23.6 |
| 12 1/4″ (311mm) TK HD Blade Cutterhead – 17 3/4″ (451mm) O.D. | ACH1214350HD | 80 | 36.3 |
